Description
SanCeram sensor operated safe touch thermostatic panel mounted HBN compliant mixer tap for healthcare environments.
Features
*Remote sensor operated
*Battery powered
*24 hour hygine flush
*Full safe touch body
*TMV3 approved thermostatic control
*HTM / SHTM compliant
*HBN compliant
*WRAS approved
*Integral isolation valves
*Isolation, check valves and filters accessible institute
*Smooth internal surfaces
*Sterilisation function for the complete tap
*5ltr/min flow regulators fitted
*Purge feature available (additional purge kit required)
Technical Specification
Max operating pressure: 5.0 bar dynamic/ 10.0 bar static
Min operating pressure: 1.0 bar
Max inlet temperature: 85⁰C
Pre-set factory temperature: 41⁰C
Finish
Chrome
Compatible extras
SCBW117: Purge kit for HBN clinical taps
SCBW123: Transformer for mains power
12 month manufacturing guarantee
